Ceramic Fibre Board 10mm

Ceramic fibre board 10mm offers both excellent thermal insulation and space efficiency. This product effectively retains heat while maintaining a thin profile. Kerui Refractory supplies multiple specifications to meet different project requirements. Customers can select from various density grades and temperature ratings.

Parameters of Kerui Ceramic Fiber Board 10mm

Ceramic fibre board 10mm is made from a slurry of refractory fibres and binders with a low organic content. The combination of different refractory fibres, inorganic and organic binders in varying proportions allows for the creation of boards suitable for different use temperatures. View the parameters.

Item	Ordinary Type	Standard Type	High Purity Type	High Alumina Type	Zirconium Containing Type
Classification Temperature, ℃	1100	1260	1260	1360	1430
Working Temperature, ℃	<1000	1050	1100	1200	1350
Bulk & Density, kg/m³	260-320
Permanent Liner Change, %	-4 (1000℃)	-3 (1000℃)	-3 (1000℃)	-3 (1250℃)	-3 (1350℃)
Heat Conductivity Coefficient, W/(m·k) (Bulk Density 128kg/m³)	0.09 (400℃), 0.176 (800℃), 0.22 (1000℃)
Strength of Extension, Mpa	0.5
Al2O3, %	44	46	46~49	52~55	39~40
Al2O3+SiO2, %	96	97	99	99	-
Al2O3+SiO2+ZrO2, %	-	-	-	-	99
ZrO2, %	-	-	-	-	15~17
Fe2O3, %	<1.2	<1.0	0.2	0.2	0.2
Na2O+K2O, %	≤0.5	≤0.5	0.2	0.2	0.2
Size, mm	Length, Width Regular Size, Thickness 3-100mm, Customized Size

Key Properties of Ceramic Fibre Board 10mm

• High Temperature Stability: Ceramic fibre boards can withstand high temperatures, making them suitable for use in extreme heat environments.
• Low Thermal Conductivity: The material exhibits low thermal conductivity, ensuring effective insulation and heat retention.
• Low Heat Storage: The board’s low heat storage capacity allows for faster heating and cooling cycles.
• Resistance to Thermal Shock: The material can withstand sudden changes in temperature without suffering damage.
• Good Erosion Resistance: Boards are resistant to erosion, making them suitable for use in harsh environments.
• Space-Saving Design: The thin profile of the 10mm board allows for more efficient use of space without compromising on insulation performance.
• Ease of Installation: The board’s lightweight and rigid nature makes it easy to handle and install.
• Versatility: Suitable for a wide range of applications, including furnace linings, boiler ducts, and kiln insulation.

Applications of Ceramic Fiber Board 10mm

• Ceramics and Glass: Insulation in furnace car seals and lining in doors and walls.
• Oil & Gas: Protection of structures and equipment, such as pyrolysis ovens and heaters.
• Power Generation: Insulation for boilers, turbines, and pipes.

Global Cases of Kerui Ceramic Fibre Insulation Board 10mm

Ceramic fibre board 10mm demonstrates excellent performance in global applications. This ceramic fibre product shows remarkable effectiveness and versatility. Below are some reviews.

Let Kerui Help You Select the Right Grade

Kerui Refractory has more than 20 years of production and construction experience and will provide you with appropriate advice. When selecting the appropriate grade of ceramic fibre board 10mm, consider the following factors:

• Application Requirements: Determine the specific needs of your project, such as temperature resistance, thermal conductivity, and mechanical strength.
• Environmental Conditions: Assess the environmental conditions the board will be exposed to, including temperature fluctuations, humidity, and potential chemical exposure.
• Budget: Consider the cost-effectiveness of the material, taking into account factors such as installation, maintenance, and long-term performance.

Conclusion

Ceramic fibre board 10mm is an excellent choice for high-performance insulation in various applications. Its optimal thickness provides a balance between thermal efficiency and space-saving design. Its key properties and advantages make it a versatile and reliable solution. Contact us now if you have needs. View more videos on YouTube.
